ADT Model 7100 Semi-Automatic Dicing System Operations Manual
Graphical User Interface
P/N 97100-9002-000-14 Ver 06/05
2.2-1
2.2 Graphical User Interface
When the software is launched, the following screen is displayed:
Each element of the main window is described in the following sections:
• Menu Bar, section 2.2.1
• Toolbar, section 2.2.2
• Gauges, section 2.2.3
• Dicer Status Indicator, section 2.2.4
• Active User Field, section 2.2.5
• Activity Log, section 2.2.6
• Blade Indicator, section 2.2.7
• Run Button, section 2.2.8
• Stop Button, section 2.2.9
• Workspaces, section 2.2.10
Figure 2-10: Model 7100 Series Opening Screen
Run Menu Bar
Blade Activity
Gauges
Indicator Log
Button
Workspace Active User
Field
Dicer Status
Indicator
Toolbar
Stop
Button
